产品特点:
※ 高亮度、大范围照明：采用4盏1000瓦金卤灯、灯杆升起10米后灯光覆盖半径可达120-150米。整体照明远近兼顾、照明距离远，照射面积大。
※ 运力强劲，经济环保：灯塔配置优质的国际知名品牌的发电机组，动力强劲。机组与底座之间采用减震设计，减少震动，使运行更加安全稳定，高效节能。
※全方位、多角度投射：灯杆可在水平方向作360度旋转调节，360度照射无死角。灯头可在垂直方向0度一90度范围内任意改变投射角度。
※人性化设计，操控简单：控制系统集成化，控制开关，控制显示屏，指示仪表全部集成与同一面板上，方便操作人员操作和实时监控。全自动操作设计，发动机启动、灯杆升降、液压支脚收放、灯具开关全部独立自动控制、操作简便轻松快捷。
※安全可靠、运输方便：液压支脚展开面积大，支撑力强，加上先进的整机一体化配重设计，具有良好的抗风性能，可保证在8级大风下可靠工作。
※ 多种移动方式，可采用拖车系统，也可采用叉车、吊车进行移动和运输。
|
序号 |
项目名称 |
参数项 |
参数值 |
|
1 |
发电机组 |
久保田美奥迪发电机组 |
KUBOTA+ MECC |
|
|
|
发动机型号 |
D1105-BG |
|
|
|
发电机型号 |
PI044F 单相 |
|
|
|
控制模块 |
DSE3110 |
|
|
|
功率 |
7.2KW |
|
|
|
电压/频率 |
220V/50HZ |
|
|
|
油耗 |
2L/h |
|
|
|
油箱容量 |
75L |
|
|
|
可连续工作时间 |
40h |
|
|
|
电气系统 |
12V |
|
|
|
噪音等级 |
≤70db 7米处 |
|
|
|
柴油型号 |
0# |
|
|
|
最大拖行速度 |
80km/h |
|
|
|
收纳尺寸 |
约2800*1650*2300mm |
|
|
|
伸展尺寸 |
约2800*3000*9000mm |
|
|
|
总重 |
1250kg |
|
2 |
灯具 |
灯具功率 |
4×1000W金卤灯 |
|
|
|
翻转角度(电动) |
0-75° |
|
3 |
灯杆 |
伸限(液压) |
9m |
|
|
|
水平旋转 |
360° |
|
|
|
上升/下降时间 |
45s/18s |
|
|
|
抗风等级 |
75km/h |
|
4 |
支撑腿 |
支撑腿支撑方式 |
手动 |
| Model | Hydraulic Mobile Light Tower | |
| Genshent Technical Data | Mo-806 | Mo-520 |
| Dimension (L*W*H)mm | 2836*1350*2480 | 2950*1350*2950 |
| Mast Height (Fully Extenled) | 9M | 10M |
| Weight ( Net ) | 1140kg | 1150kg |
| Rated Voltage | 220V(Single Phase ) | |
| Rated Power | 6KVA | |
| Power Outlet Sockets | 2PCS*10A ( AC220V 1 Phase ) | |
| Input Voltage | 220V(Single Phase ) | |
| Fuel Tank Capacity | 100liters (26.5US Gallons) | |
| Fuel Tank Operating Hours | 50 hours | |
| Fuel Consumption (g/kw.h) | NA/252/248 | |
| Acoustic Pressure | 62dB (A) at 7 away | |
| Load Capacity For 40"HC(Units ) | 8 | |
| Engine | Perkings | Kubota |
| Engine Model | 403D-11G | D1105 |
| Speed (Rpm) | 1500/1800 | 1500/1800 |
| Prime Power ( Kw ) | 8.4/10.3 | 8.4/10.1 |
| Cooling System | water -cooled | water -cooled |
| Oil Capability | 4.9L | 5.1L |
| Emission Level | NA / Tier 4 optional | NA / Tier 4 optional |
| Alternator | Italy Mecc alte | Italy Mecc alte |
| Alternator Model | LT3N-130/4(100/4) | LT3N-130/4(100/4) |
| Frequency ( Hz ) | 50/60 | 50/60 |
| Continued Power (Kw) | 6 | |
| Alternator | Brushless Single phase | |
| Excitation Mode | Capacitor exciter | |
| Rating Voltage (V ) | 220V | |
| Alternator Insulation | H | |
| Protection Grade | Ip23 | |
| Mast | Hydraulic Type | |
| Mast Height | 9m | 10m |
| Section No.(Extended) | 9 | |
| Mast Rotation | 360 ° manual | |
| Mast Extension Time | 14 Seconds | |
| Mast Descend Time | 20 Seconds | |
| Lighting | LAMP | |
| Type of lights | Metal Halide Lamp | |
| Number Power of Lights | 4*1000W | |
| Mast Lighting & Extension | Hydraulic Operation | |
| Light angle turning | Electric | |
| Luminous Efficiency | 80Lumens/ Watt | |
| Lamps Rotation | 75° （ Automatic ) | |
| Protection Glass | IP65 | |
| Luminous Flux | 4*99000LM | |
| Color Temperature | 4000K | |
| Trailer | Trailer | |
| Manufacturer | AL-KO | SUOEN |
| Braking System | Parking Barcking /Driving barking is option | |
| Hitch | Ball Type /O Ring for option | |
| Tire Rim Size | 185/14" | |
| Speed (Rpm) | <80km/h | |
